Due to fact that the insert is adjustable / removable from the front of the mold, there is no need to remove the tool from the machine or disassemble the mold.
Read moreShow less
Which is the recommended screwdriver width to manipulate the CUMSA date stamps / inserts?
</tr
| Ref | Screwdriver |
| FX04.... IX21.... |
1.2mm x 0.2mm. (0.047" x 0.0079") |
| FX05.... IX31.... |
1.5mm. x 0.25mm. (0.059" x 0.0098") |
| FX06.... IX32.... |
1.8mm. x 0.3mm. (0.071" x 0.0118") |
| FX08.... IX47.... |
2mm. x 0.4mm. (0.079" x 0.0157") |
| FX10.... IX57.... |
2.5mm. x 0.4mm. (0.098" x 0.0157") |
| FX12.... IX67.... |
3mm. x 0.5mm. (0.118" x 0.0197") |
Are special engravings possible?
Yes, you can request a special engravings on all our date stamps.
How deep is the engraving on the Xtra Date Stamp - FX?
| Ref | Numbers | Line |
| FX04.... IX21.... | 0,15mm. (0.006") | 0,35mm. (0.014") |
| FX05.... IX31.... | 0,15mm. (0.006") | 0,40mm. (0.016") |
| FX06.... IX32.... | 0,15mm. (0.006") | 0,40mm. (0.016") |
| FX08.... IX47.... | 0,15mm. (0.006") | 0,40mm. (0.016") |
| FX10.... IX57.... | 0,15mm. (0.006") | 0,50mm. (0.020") |
| FX12.... IX67.... | 0,15mm. (0.006") | 0,50mm. (0.020") |
What type of thread does the FX/IX have?
| Ref | Thread |
| FX04.... IX21.... |
M1.1 x 0.25mm. |
| FX05.... IX31.... |
M1.6 x 0.2mm. |
| FX06.... IX32.... |
M2 x 0.25mm. |
| FX08.... IX47.... |
M2.5 x 0.25mm. |
| FX10.... IX57.... |
M3 x 0.35mm. |
| FX12.... IX67.... |
M4 x 0.35mm. |
