Cooled Compact Slide 42x24 (Stroke 9mm)

Simplify your mold design. Reduce costs. Improve precision.

With CUMSA’s Cooled Compact Slide, precision alignment is easier, faster, and more cost-effective than ever.

Cooled version of the Compact Slide, when used with the desired MR hose, cools the insert, thereby reducing the part’s cycle time and increasing productivity.

GREAT ADVANTAGES

Adjustable design

The insert has pre-drilled starter holes for easy customization and installation of the cooling channels.

Self-Centering Precision
The slide comes with a floating, self-centering insert during mold closing for consistent, accurate results. Its secret: the horizontal and vertical movement of up to ±0.5 mm.

Minimal Machining Required
Only the insert piece requires precision machining (a 10 º cone to be mechanized by the customer). No tight housings are needed on the rest of the slide.

Fast & Simple Installation
Just three screws required: one on the ejection side and two on the injection side.

Reduced Wear & Maintenance
Its magnetic plate minimizes friction, and the retainer securely holds the slide in place during the ejection process.

Cost reduction
No angle pins, lateral sliding guides or external retainers needed, cutting costs by up to 50% compared to conventional slides.

Built for Efficiency & Reliability
Fewer components, faster setup, and simplified maintenance improve overall mold performance and longevity.
