Possibilitat de instal•lar per sobre dels circuits de refrigeració, ja que es desmunten per la part frontal (amb l’útil EF).
El insert sempre es manté al mateix nivell que el cos del datador.
Posicionament exacte del datador en el seu allotja ment.
Zona òptima de clavat.
Read moreShow less
El insert sempre es manté al mateix nivell que el cos del datador.
Posicionament exacte del datador en el seu allotja ment.
Zona òptima de clavat.
What is the maximum temperature that a Date Stamp can withstand?
The Date Stamp can work up to 150 °C (302°F).
How deep is the engraving on Date Stamps?
| Ref | Numbers | Arrow |
| FP04.... IA22…. | 0.15mm. (0.006") | 0.35mm. (0.014") |
| FP05.... IA30 | 0.15mm. (0.006") | 0.40mm. (0.016") |
| FP06.... IA32.... | 0.15mm. (0.006") | 0.40mm. (0.016") |
| FP08.... IA47.... | 0.15mm. (0.006") | 0.40mm. (0.016") |
| FP10.... IA57.... | 0.15mm. (0.006") | 0.50mm. (0.020") |
| FP12.... IA67.... | 0.15mm. (0.006") | 0.50mm. (0.020") |
| FP16.... IA87.... | 0.15mm. (0.006") | 0.70mm. (0.028") |
| FP20.... IA107... | 0.15mm. (0.006") | 0.70mm. (0.028") |
What kind of thread is on Date Stamps and Inserts?
| Ref | Arrow |
| FP04.... IA22.... | M1.6x0.35mm. |
| FP05.... IA30.... | M1.6x0.35mm. |
| FP06.... IA32.... | M2.5x0.45mm. |
| FP08.... IA47.... | M3.0x0.50mm. |
| FP10.... IA57.... | M3.0x0.50mm. |
| FP12.... IA67.... | M3.5x0.60mm. |
| FP16.... IA87.... | M3.5x0.60mm. |
| FP20.... IA10.... | M3.5x0.60mm. |
The Insert turns within the Date Stamp when injecting. What is the reason for this?
In order to place the Insert correctly into the Date Stamp, turn it with a screwdriver clockwise until you hear a "click". Once the Insert is securely placed, turn it clockwise for changing the indication. To remove the Insert, turn it with a screwdriver counter-clockwise.
Which is the recommended screwdriver width to manipulate the CUMSA date stamps / inserts?
| Ref | Screwdriver |
| FP04.... IA22.... | 1.2mm x 0.2mm. (0.047" x 0.0079") |
| FP05.... IA30.... | 1.5mm. x 0.25mm. (0.059" x 0.0098") |
| FP06.... IA32.... | 1.8mm. x 0.3mm. (0.071" x 0.0118") |
| FP08.... IA47.... | 2mm. x 0.4mm. (0.079" x 0.0157") |
| FP10.... IA57.... | 2.5mm. x 0.4mm. (0.098" x 0.0157") |
| FP12.... IA67.... | 3mm. x 0.5mm. (0.118" x 0.0197") |
| FP16.... IA87.... | 4mm. x 0.8mm. (0.157" x 0.0315") |
| FP20.... IA10.... | 4mm. x 0.8mm. (0.157" x 0.0315") |
Are special engravings possible?
Yes, you can request a special engravings on all our date stamps.
